Unbalanced 1xN Mini Fiber Optic PLC Splitter
Optical Splitter
New
Custom pricing — request a quote below
The Fybronix Unbalanced 1xN Mini PLC Splitter delivers flexible, asymmetric optical power distribution in a compact form factor. Available in 1x3, 1x5, 1x6, 1x9, and 1x12 configurations with customizable split ratios. Ideal for PON networks requiring unequal signal distribution across multiple output ports.
Need 50+ cables? Get business account pricingIn stock (10000 available)Total available: 10000
Free shipping over $50.00
24/7 customer support
30-day returns
Usually ships in 3 days
Up to 10000 available in stock.
In Stock - Ships from Ohio within 24 hours
Includes product image, specifications, and features.
Specifications
| Split Ratio | 85/15, 80/20, 70/30, 60/40 |
|---|---|
| Operating Wavelength (nm) | 1260-1650 |
| Fiber Type | G657A or customized |
| IL_max Channel 1 (dB) | 1.6 |
| IL_max Channel 2-9 (dB) | 21.0 |
| IL_uni Channel 2-9 (dB) | 1.8 |
| Return Loss (dB) | ≥55 |
| Directivity (dB) | ≥55 |
| PDL max. | 0.3 |
| Uniformity max. | 0.8 |
| Wavelength Dependent Loss (dB) | ≤0.3 |
|---|---|
| TDL max. | 0.5 |
| Operating Temperature | -40 ~+85 |
| Storage Temperature | -40 ~+85 |
| Connector Options | SC/UPC, SC/APC, LC/UPC, LC/APC, none |
| Pigtail Length | 0.35m to 1.5m |
| Form Factor | Mini (bare fiber) |
| Testing | 100% 3D tested + high-low temperature cycle tested |
