1xN ABS Module PLC Splitter | Compact Plug-and-Play Optical Splitter
Optical Splitter
New
Custom pricing — request a quote below
The Fybronix 1xN ABS PLC Splitter delivers reliable, uniform optical power distribution in a compact ABS module housing. Available in 1x2 through 1x128 split configurations with SC/UPC, SC/APC, LC/UPC, and LC/APC connectors. Low PDL, high return loss, and plug-and-play ready for FTTH and PON deployments.
Need 50+ cables? Get business account pricingIn stock (10000 available)Total available: 10000
Free shipping over $50.00
24/7 customer support
30-day returns
Usually ships in 3 days
Up to 10000 available in stock.
In Stock - Ships from Ohio within 24 hours
Includes product image, specifications, and features.
Specifications
| Form Factor | ABS Module |
|---|---|
| Module Components | PLC Splitter chip + ABS Module + SC/UPC Connector |
| Split Configurations | 1x2 to 1x128 |
| Connector Options | SC/UPC, SC/APC, LC/UPC, LC/APC |
| Pigtail Length | 0.35m to 1.5m |
| Wavelength | 1260~1650 (nm) |
| Insertion Loss 1x2 (dB) | <=4.6 |
| Insertion Loss 1x4 (dB) | <=7.5 |
| Insertion Loss 1x8 (dB) | <=11.0 |
| Insertion Loss 1x16 (dB) | <=14.0 |
| Uniformity 1x2 (dB) | <=0.6 |
|---|---|
| Uniformity 1x4 (dB) | <=0.6 |
| Uniformity 1x8 (dB) | <=0.8 |
| Uniformity 1x16 (dB) | <=1.2 |
| PDL 1x2 (dB) | <=0.2 |
| PDL 1x4 (dB) | <=0.2 |
| PDL 1x8 (dB) | <=0.2 |
| PDL 1x16 (dB) | <=0.3 |
| Directivity (dB) | ≥55 |
| Operating Temperature | -40~+85 |
