0.9mm Simplex Fiber Optic Pigtail | Single Mode & Multimode
Pigtail
New
Custom pricing — request a quote below
The Fybronix 0.9mm Simplex Fiber Optic Pigtail delivers single-strand precision termination for ODF units, patch panels, and splice enclosures. Available with SC, SC/APC, LC, LC/APC, FC, FC/APC, ST, and MTR connectors in both single mode and multimode configurations. Factory polished, 100% tested, and RoHS compliant.
Need 50+ cables? Get business account pricingIn stock (2000 available)Total available: 2000
Free shipping over $50.00
24/7 customer support
30-day returns
Usually ships in 3 days
Up to 2000 available in stock.
In Stock - Ships from Ohio within 24 hours
Includes product image, specifications, and features.
Specifications
| Configuration | Simplex (1 fiber) |
|---|---|
| Fiber Type | Single Mode (OS2) / Multimode (OM1-OM4) |
| Fiber Glass Type | G652 / G657 |
| Core/Cladding Diameter | 9/125µm (SM) |
| Cable OD | 0.9mm |
| Connector Options | SC, SC/APC, LC, LC/APC, FC, FC/APC, ST, MTR |
| Endface Polish | PC / UPC / APC |
| Ferrule Material | Ceramic |
| Typical Insertion Loss | <0.2 dB (PC) / <0.15 dB (UPC) |
| Return Loss | ≥45 dB (PC) / ≥50 dB (UPC) |
| Insert-Pull Test | <0.2 dB |
|---|---|
| Interchangeability | <0.1 dB |
| Available Lengths | 1M / 2M / 3M / Custom |
| Quality Testing | 100% tested per unit |
| Compliance | Telcordia GR-326-Core / IEC / RoHS |
