Fiber Patch Cord LC UPC to SC UPC SX Yellow
Fiber Patch Cables
FeaturedNew
$2.49
Need 50+ cables? Get business account pricingNot availableTotal available: 400
Size
Free shipping over $50.00
24/7 customer support
30-day returns
Usually ships in 3 days
Includes product image, specifications, and features.
Specifications
| Connector Type | LC/UPC to SC/UPC |
|---|---|
| Mode | Single Mode |
| Fiber Type | G657A1 |
| Cable Diameter | Φ2.0mm |
| Jacket Material | LSZH |
| Color | Yellow |
| Length | 1 Meter |
| Weight | 13g (0.013 KG) |
| Insertion Loss | <0.2 dB |
| Return Loss | ≥50 dB |
| Fiber Height (Extensibility) | -0.05μm to +0.05μm |
|---|---|
| Face Radius | 10mm to 30mm |
| Vertex Deviation | <50μm |
| Durability | 500+ mating cycles |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +80°C |
| Humidity | 95% RH (non-condensing) |
| 3D Interferometric Pass Rate | 85% |
